Coil Voltage:
12V dc
Contact Configuration:
DPDT
Mounting Type:
Surface Mount
Maximum Switching Current AC:
2 A
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V
Series:
HFD4
Maximum Switching Power DC:
60 W
Latching:
No
Length:
10mm
Depth:
6.5mm
Height:
5.65mm
Dimensions:
10 x 6.5 x 5.65mm
Terminal Type:
Through Hole
Number of Poles:
2
Switching Current:
2A
Features:
Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available
Electrical Life:
100000 Operations
Coil Resistance:
1028Ω
Operating Temperature Range:
-40 → +85°C
Relay Switching Classification:
Subminiature Signal Relay
Contact Material:
Gold Plated
Coil Power:
140mW
Maximum Switching Power AC:
62.5VA
Life:
1 x 10^8 cycles
Isolation Coil To Contact:
2.5kV ac
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-40°C
