Coil Voltage:
24V dc
Contact Configuration:
SPST
Mounting Type:
Surface Mount
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
250V ac
Maximum Switching Voltage DC:
220V dc
Series:
DS
Maximum Switching Power DC:
60 W
Length:
20mm
Latching:
No
Depth:
9.9mm
Height:
9.4mm
Dimensions:
20 x 9.9 x 9.9mm
Terminal Type:
PCB Pin
Switching Current:
3A
Number of Poles:
1
Application:
General Purpose, Office Equipment, Safety, Telecommunications
Coil Power:
400mW
Maximum Operating Temperature:
+70°C
Life:
10^7 (Mechanical) Operations, 5 x 10^5 (Electrical) Operations
Maximum Switching Power AC:
125VA
Coil Resistance:
1920Ω
Operating Temperature Range:
-40 → +70°C
Features:
Suitable For Use In Difficult Environments, Gold Clad Twin Contacts Ensure High Reliability, Can Be Used With Automatic Solder And Automatic Wash Systems
Contact Material:
Gold Plated
Minimum Operating Temperature:
-40°C
Isolation Coil To Contact:
1.5kV rms
Electrical Life:
5000000 Operation Cycles
