Multimeter Type:
Handheld
Model Number p:
RS-9889
Display Type:
Digital
Calibrated:
RSCAL
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature, Thermal Imaging
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+1000°C
Absolute Maximum Capacitance Measurement:
6mF
Moulded/Fold Flat:
Bluetooth
Maximum Frequency:
10MHz
DC Current Measurement Resolution:
0.1µA dc
AC Current Measurement Resolution:
0.1µA ac
AC Voltage Measurement Resolution:
0.001V ac
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.1mV dc
Temperature Measurement Resolution:
0.1°C
Safety Category Level:
CAT III, CAT IV
Capacitance Measurement Resolution:
0.01nF
Best Temperature Measurement Accuracy:
±1.5 % + 3°C
Best AC Voltage Accuracy:
±2.4 % + 5 Digits
Best Capacitance Measurement Accuracy:
±2.5 % + 20 Digits
Minimum Operating Temperature:
-20°C
Height:
195mm
Weight:
540g
Best DC Current Accuracy:
±1.5 % + 8 Digits
Battery Type:
Li-Ion
Best Resistance Measurement Accuracy:
±2.5 % + 10 Digits
Maximum Operating Temperature:
+260°C
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
±1.5 % + 5 Digits
Width:
58mm
Length:
80mm
Dimensions:
80 x 58 x 195mm
Best DC Voltage Accuracy:
±0.2 % + 5 Digits
