Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
IDM66RT
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum Temperature Measurement:
+400 °C, +752°F
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
10mF
Maximum Frequency:
500Hz
DC Current Measurement Resolution:
0.001A dc
AC Current Measurement Resolution:
0.001A ac
AC Voltage Measurement Resolution:
1mV ac
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.01mV dc
Safety Category Level:
CAT III
Temperature Measurement Resolution:
0.1 °F, 0.1°C
Capacitance Measurement Resolution:
0.01nF
Best DC Voltage Accuracy:
±0.5% + 2 Digits
Minimum Operating Temperature:
-10°C
Width:
44mm
Best AC Current Accuracy:
±1.5% + 5 Digits
Length:
74mm
Best AC Voltage Accuracy:
±1% + 5 Digits
Safety Category Voltage:
600V
Height:
156mm
Dimensions:
74 x 44 x 156mm
Weight:
250 (With Battery)g
Best Temperature Measurement Accuracy:
±1 % + 10 Digits
Best DC Current Accuracy:
±1% + 2 Digits
Best Resistance Measurement Accuracy:
±0.8% + 2 Digits
Best Capacitance Measurement Accuracy:
±1.9% + 8 Digits
Battery Type:
AAA 1.5 V, AM4, IEC LR03
Maximum Operating Temperature:
+50°C
