Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
IDM72
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum Capacitance Measurement:
6mF
True RMS:
Yes
Maximum Frequency:
60MHz
AC Current Measurement Resolution:
0.1µA ac
DC Current Measurement Resolution:
0.1µA dc
AC Voltage Measurement Resolution:
0.1mV ac
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.1mV dc
Capacitance Measurement Resolution:
1pF
Safety Category Level:
CAT III, CAT IV
Best DC Current Accuracy:
±1% + 2 Digits
Weight:
400g
Minimum Operating Temperature:
0°C
Height:
164mm
Safety Category Voltage:
600 V, 1000V
Battery Type:
9V, IEC 6F22, NEDA 1604
Maximum Operating Temperature:
+50°C
Best Resistance Measurement Accuracy:
±0.7% + 2 Digits
Best AC Current Accuracy:
±1.5% + 5 Digits
Best DC Voltage Accuracy:
±0.5% + 2 Digits
Dimensions:
82 x 44 x 164mm
Best Capacitance Measurement Accuracy:
±1.9% + 8 Digits
Best AC Voltage Accuracy:
±0.9% + 5 Digits
Length:
82mm
Width:
44mm
